C6-1 Zoning is a General Central Commercial Zoning district in NYC. In C6-1 you can build a variety of commercial building uses, community facilities, and residential buildings.
The C6-1 Zoning District is a sub district of C6 Zoning in NYC. C6 is a general central zoning district with generally large buildings having retail, department stores, large offices, hotels, and residential uses. C6-1 Zoning is mapped in Downtown Manhattan, and a small part of Harlem.
C6-1 Zoning Districts:
C6-1 Residential Equivalent:
C6-1 Residential Equivalent
Most Commercial Zoning districts have a Residential Equivalent. This means you can develop a residential building within the commercial zoning district. You follow the residential equivalent zoning requirements in the case of a residential development. The residential equivalent for C6-1 is R7-2 Zoning.
Mixed Use Building
You can develop a mixed use building with commercial and residential zoning. In this case you would apply the requirements of C6-1 and R7-2 in designing the building.
C6-1 Zoning Specifications
C6-1 Commercial Floor Area Ratio (FAR):
Floor Area Ratio determines the floor area that can be built on the property.
FAR = 6
Residential FAR usually differs from Commercial.
C6-1 Community Facility Floor Area Ratio
FAR = 6.5
Community Facility usually gets a higher floor area ratio.
Plaza Floor Area Bonus:
1 to 4 ratio plaza to building floor area bonus
In C6-1 the Plaza Bonus applies to buildings with commercial or community facility use.
You can build 4 additional square feet of building for every square foot of plaza. Plazas have specific requirements not all locations qualify.
Arcade Floor Area Bonus
1 to 2 ratio arcade to building floor area bonus
In C6-1 the arcade Bonus applies to buildings with commercial or community facility use.
You can build 2 additional square feet of building for every square foot of arcade. Arcades have specific requirements not all locations qualify.
Yard Requirements for Commercial Use in C6-1
Side Yards are not required, but if side yards are provided they must comply with the following:
At minimum 8 feet in width or
At minimum 5 feet in width with an average width of 8 feet.
Some special circumstances will require side yards.
20 Foot rear yard required
C6-1 Height And Setback
Initial Setback Distance
20 feet on narrow street
15 on wide street
Building Height Within Initial Setback Distance = 85 feet or 6 stories whichever is less
Sky Exposure Plane Vertical to Horizontal
Narrow Street Sky Exposure Plane = 2.7 to 1
Wide Street Sky Exposure Plane = 5.6 to 1
C6-1 Alternate Height And Setback
Alternate height and setback regulations can apply if you provide open space for the entire length of the front lot line.
Depth Of Optional Front Yard
15 feet on narrow street
10 on wide street
Sky Exposure Plane Height Above Street Line = 85 feet
Sky Exposure Plane Vertical to Horizontal
Narrow Street Sky Exposure Plane = 3.7 to 1
Wide Street Sky Exposure Plane = 7.6 to 1
You should always make sure if your property is subject to Sliver Law restrictions.
As an architect I study zoning very closely. NYC Zoning is complicated and quite involved. In this article we reviewed some of the basic Zoning Codes with regards to commercial zoning district C6-1. This analysis does not assume to cover every possible issue and condition, but provide a general overview. This post does not substitute the NYC Zoning Resolution.
